| Payload capacity | 10kg | |
| Allowable moment | 29.4Nm (300 kgf-cm) | |
| Allowable torque | 34.3Nm (350 kgf-cm) | |
| Housing diameter | φ60mm | |
| Combined profile | 46.5mm | |
| Main body material | Aluminum Alloy | |
| Position repeatability | 0.020mm | |
| Air pressure for Working | 0.39 ～ 0.85Mpa (4 to 8.7 kg/cm²) | |
| Weight | Robot side | 0.24kg |
| Tool side | 0.12kg | |
| Electrical signal |
Current | 3A |
| Quantity | None or 15 pins | |
| Pneumatic Port |
Quanitity | 6 Ports(M5) |
| Effective cross section |
4mm2 | |
| CV value | 0.23/port | |
| Max pressure | 0.855Mpa(8.75kg/cm²) | |
| Surrounding Condition |
Temperature | 0～60℃ *1 |
| Humidity | 0～95％RH *2 | |
＊1 No freeze
＊2 No condensation
